The liquid-filled Bourdon tube pressure gauge is constructed with a case from stainless steel and wetted parts from copper alloy. WIKA manufactures and qualifies the pressure gauge in accordance with the standards EN 837-1 and ASME B40.100. As a safety function, this instrument has a blow-out device. In the event of a failure, overpressure can escape there.
Steam Instrumentation
WIKA 213.30
BOURDON TUBE PRESSURE GAUGE
- Material
- Stainless Steel
- Sizes
- 1/2"
- Connection
- Threaded
- Pressure
- up to 40 Bar
From
£194.00ex VAT
Choose an article number from the sizes & pricing table to add it to your quote, or send us an enquiry.
Need help choosing? Call our sales engineers on 01608 645755
Standard Features
- Vibration and shock resistance
- Robust design
- Type approval for the shipbuilding industry
- Scale ranges to 0 ... 1,000 bar or 0 ... 15,000 psi
| Model | 213.50 |
|---|---|
| Material | Stainless Steel |
| Sizes | 1/2" |
| Connection | Threaded |
| Pressure | up to 40 Bar |
| Division | Steam |
| Category | Instrumentation |
| Type | Pressure Transmitters - Gauges & Syphons |
Use the enquiry form below to ask about this product, or add a quantity to any line and press Add to build a sales order. Open the basket icon at the top of the page to review and send it.
PLEASE NOTE: the prices shown are full list prices. If you have an account with us these will be updated by our team once your order is placed.
| Article no. | Description | Price £ | Price € | Quantity |
|---|---|---|---|---|
| 213002 | 213.53.100 (0-2.5 BAR) | 1/2" LM PRESSURE GAUGE | £194.00 | €232.00 | |
| 213006 | 213.53.100 (0-6 BAR) | 1/2" LM PRESSURE GAUGE | £194.00 | €232.00 | |
| 213010 | 213.53.100 (0-10 BAR) | 1/2" LM PRESSURE GAUGE | £194.00 | €232.00 | |
| 213016 | 213.53.100 (0-16 BAR) | 1/2" LM PRESSURE GAUGE | £194.00 | €232.00 | |
| 213025 | 213.53.100 (0-25 BAR) | 1/2" LM PRESSURE GAUGE | £194.00 | €232.00 | |
| 213040 | 213.53.100 (0-40 BAR) | 1/2" LM PRESSURE GAUGE | £194.00 | €232.00 |
